Indoor Rental Series| Aluminum Die-casting Rental Series480*480

Specification of Indoor Rental Series| Aluminum Die-casting Rental Series480*480)|p4, p5, p6



Parameters Aluminum Die-casting Rental(480*480)
Pixel Pitch (mm) 4mm 5mm 6mm
Pixel density(pix/m2) 62500 40000 27777
LED Type SMD2020 SMD3528
Viewing Angle HZ:140°,V:140°
Brightness(nits) 1600 1500 1800
Drive Method 1/15 1/12 1/10
Driving IC MBI5024
Color Depth 16bit
Refresh Rate(Hz) 600 1200
Module Size (mm) 240×240
Cabinet Size(mm) 480×480
Cabinet Material Die-cast aluminum
Cabinet weight(kg) 9.5kg
Voltage 110/250V
Average.power(W / m2) 585
Max.power (W / m2) 1300
IP Grade IP31
Operating temperature/humidity temperature:-20℃~ 50℃ humidity:10~90%RH
Storage temperature/ humidity temperature:-40℃~ 60℃ humidity:10~90%RH
Lifetime(h) ≥50000
Compliant Standard CCC、CE

features of Indoor Rental Series| Aluminum Die-casting Rental Series480*480)|p4, p5, p6

Humanized structure designing guarantees the minimum assembly gap as 0.1mm between cabinets, Thickness of this cabinet is only 76.4mm

Equipped with patented fast locks,durable and graceful. Easy assembly and dismantling

Speedy heat venting designing ensures steady cooling of the cabinets even equipped no fans

A light base lessens the space,occupied by the display.
