Pixel Pitch | 0.88mm |
Pixel configuration | 1R1G1B |
LED type | 3-in-1 SMD0606 |
Brightness | 800 cd/m² |
Color temperature | 6500K |
Viewing angle | H: 160°; V:160° |
Module size | 240mm×240mm |
Cabinet size | W480mm×H480mm×D86mm |
Weight | 8kg/panel |
Area | 0.2304 m² |
Material | Die-casting Aluminum |
Ingress protection | IP30 |
Operating Temperature | 0℃~+45℃/10~90%RH |
Gray scale | 16 bits |
Processing depth | 65536 levels per color |
Color | 281.4 trillion |
Brightness control | Manual/Automatic |
Contrast ratio | 3000:01:00 |
Video frame rate | 50/60 Hz |
Rate refresh | ≥2000 Hz |
Input voltage | 110~240VAC |
Input power frequency | 50~60 Hz |
Life Time | ≥100,000 Hours |
LED Wavelength | R:620~630nm G:520~535nm B:465~475nm |
Driving Method | 1/27 Scan, Constant Current |
Rigging form | Hanging/Fixed with support bracket |
