Item | X Series Indoor Rental Screen | |||
Pixel Pitch(mm) | 3.91mm | 4.81mm | 5.28mm | 6.25mm |
Pixel density(dot/m2) | 65536 | 43264 | 32580 | 25600 |
LED Type | SMD2020 | SMD2020 | SMD3528 | SMD3528 |
Viewing angle: | H:140°,V:140° | H:140°, V:140° | H:140°, V:140° | H:140°, V:140° |
Brightness(nits) | ≥1400 |
Drive Method | 1/16. | 1/13. | 1/12. | 1/10. |
Color Depth(nits) | 16 | |||
Refresh Rate(Hz) | 1200 | 1200 | 1400 | |
Module Size(mm) | 250×250×17 | 250×250×17 | 250×250×17 | 250×250×17 |
Cabinet Size(mm) | 500×1000×70 | 500×1000×70 | 500×1000×70 | 500×1000×70 |
Cabinet Material | Aluminum Sheet Metal | |||
Cabinet weight(kg) | 14 | 14 | 11 | 9 |
Voltage | 110/240V | |||
Average.power(W / m2) | 200 | 195 | 520 | 300 |
Max.power(W / m2) | 600 | 580 | 640 | 680 |
IP Grade | IP31 | |||
Operating temperature/humidity | Temperature:-20℃~ 50℃ humidity:10~90%RH | |||
Storage temperature/humidity | Temperature:-40℃~ 60℃ humidity:10~90%RH | |||
Lifetime(h) | ≥50000 |
