The VX4S is a professional LED display controller. Besides the function of display control, it also features in powerful front end processing, so an external scalar is no longer needed. With professional interfaces integrated, VX4S with excellent image quality and flexible image control greatly meet the needs of the broadcast industry, Its friendly in user-interface. so that the display to work has never been as easier and more enjoyable as with VX4S.
Input Index |
||
| Port | Number | Resolution Specification |
| CVBS | 2 | PAL/NTSC |
| VGA | 2 | VESA Standard, support max. 1920×1200@60Hz input |
| DVI | 1 | VESA Standard (support 1080i input), support HDCP |
| SDI | 1 | 480i,576i,720P,1080i/P |
| HDMI | 1 | EIA/CEA-861 standard, in accordance with HDMI-1.3 standard, support HDCP |
| DP | 1 | VESA Standard |
Output Index |
||
| Port | Number | Resolution Specification |
| DVI LOOP | 1 | Consistent with DVI input |
| VGA | 1 |
Monitoring output connector Up to 1920×1200@60Hz output resolution |
| DVI | 1 | |
| SDI LOOP | 1 | Consistent with SDI input |
| LED OUT | 4 | 4 Gigabit Ethernet outputs. Only Ethernet port 1 supports audio output. When the multifunction card is connected for audio decoding, the multifunction card must be connected to the Ethernet port 1. |
